Double Coin RT500 285/70R19.5 H/16PLY

Commercial Truck - All Position
Commercial All Position

Rims Not Included

easy test score

7.8 Great

Availability

In Stock

Per Tire:

$270.78

$109.24

Estimated Delivery

Shipping

Total

See full specs

About the Manufacturer:

Double Coin, founded in 1990, is a major global manufacturer of radial truck, bus, and OTR (Off-the-Road) tires, with a rich manufacturing heritage dating back to 1929. Operating in over 100 countries, Double Coin is recognized for its durable and high-value commercial tires, offering exceptional longevity, reliability, and retreadability for trucks, buses, and various industrial vehicles. Double Coin holds Original Equipment (OE) supply agreements with leading trailer manufacturers, including Wabash National and Vanguard National Trailer Corp., highlighting the industry's trust in its product quality for demanding applications.

Chat

Start chat

Call

(866) 335-8473

We can help! Our trained experts have years of tire fitment experience and are available to answer questions.

Specifications
Shipping & Payment
Financing
Size Details
OE Fitment

Specifications

Specs

Value

Description

Sidewall

Not Available

Describes the sidewall appearance. Examples: BSW= Black Side Wall, WSW = White Side Wall, OWL = Outlined White Letters.

Load Index

145

The load index (LI) is a 2- or 3-digit number that correlates to the maximum amount of weight the tire can carry. For example, a tire with a load index of 87 indicates that the tire can carry a maximum load of 1,201 lbs. In this particularly example, 4 tires (each with a load index of 87) can carry a maximum of 4,804 lbs. Refer to your vehicle owner's manual for the recommended minimum load index.

Speed Rating

Speed rating (SR) indicates the maximum speed the tire can achieve. Higher speed ratings are typically associated with better handling capabilities. Refer to your vehicle owner's manual for the recommended minimum speed rating.

Load Range/Ply Rating

H/16PLY

Ply rating, more commonly referred to as load range, represents the strength and durability of the tire. Higher ratings may indicate your tires can handle heavier loads.

UTQG

Not Available

To help consumers evaluate their tires, the U.S. National Highway Traffic Safety Administration (NHTSA) created the Uniform Tire Quality Grading System (UTQG). The UTQG rates tires are rated on their tread-wear, traction performance, and temperature resistance. The grade for each of these can be found on the sidewall of your tire (except for winter tires and certain light truck tires).

Max Single Load(lbs)

6390

The maximum load this tire will support. Remember to multiply this number by the number of tires installed on your vehicle to get the maximum carrying capacity. This number is directly related to the Load Index.

Max Single Air Pressure(PSI)

123

The maximum air pressure this tire will support. This does not represent the amount of air pressure your tires should have at all times. Consult with your owner's manual to determine the best air pressure you should use for your vehicle.

Tread Depth

16.0

The amount of tread on the tire. Once the tire is worn to 2/32nds, it is considered fully used and should be replaced at that time. Most tires will have tire indicators in the grooves of the tire to help you determine when the tires are worn down to 2/32nds.

Tread Design

Nondirectional

The pattern of the grooves, lugs, voids, and sipes on a tire's surface. This design affects the tire's traction, handling, and noise characteristics. Common types include symmetrical (uniform pattern across the tire), asymmetrical (different patterns on the inside and outside for varied road conditions), and directional (designed to rotate in one direction for improved wet traction and hydroplaning resistance).

Rim Width Range

8.2-8.2

The approved wheel rim width range this tire will support.

Measured Rim Width

Not Available

The recommended wheel width as recommended by the tire manufacturer to get the best wear us performance for this tire.

Section Width

Not Available

The measurement from sidewall to sidewall.

Tread Width

Not Available

The measurement from one side of the tread to the other side of the tread.

Overall Diameter

Not Available

The height of the tire when fully inflated.

Manufacturer Part Number

1133398796

Manufacturer part number (sku)

Size Details

Size	Load Index/ Speed index	UTQG	Load Range/Ply Rating	Overall Diameter	Section Width	Rim Width Min	Rim Width Max	Rim Width Meas	Tread Depth (in)	Max Single Air Pressure (PSI)	Max Single Load (lbs)	Max Dual Air Pressure (PSI)	Max Dual Load (lbs)	MFG #
7.50R16	122/118L	-	G/14PLY	31.7	8.3	-	-	6.0	16.0	112	3305	112	2910	1132697565
8R17.5	118/116L	-	E/10PLY	30.9	8.2	-	-	6.0	16.0	95	2910	95	2755	1133391783
8R19.5	124/122M	-	F/12PLY	34.1	8.2	-	-	6.0	16.0	110	3525	110	3305	1133390894
8.25R15	129/127K	-	G/14PLY	33.2	9.1	-	-	6.5	16.0	120	4080	120	3860	1132598256
8.25R15	143/141K	-	J/18PLY	33.2	9.1	-	-	6.5	16.0	123	6005	123	5675	1132598257
10.00R15	141/139L	-	H/16PLY	36.3	10.8	-	-	7.5	16.0	120	5675	120	5355	1132591056
10.00R15	148/145K	-	J/18PLY	36.3	10.8	-	-	7.5	16.0	123	6940	123	6390	1132591057
10R17.5	143/141L	-	H/16PLY	33.9	9.8	-	-	7.5	16.0	123	6005	123	5675	1133391706
215/75R17.5	135/133K	-	H/16PLY	30.4	8.5	-	-	6.0	16.0	125	4805	125	4540	1133391776
225/70R19.5	125/123M	-	F/12PLY	32.3	8.8	-	-	6.75	16.0	95	3640	95	3415	1133392795
235/75R17.5	143/141K	-	H/16PLY	31.6	9.2	-	-	6.75	16.0	125	6010	125	5680	1133396795
235/75R17.5	143L	-	J/18PLY	-	9.2	6.7	6.7	-	16.0	125	6010	-	-	1133396797
245/70R17.5	143/141J	-	J/18PLY	31.1	9.9	-	-	7.5	17.0	127	6005	127	5675	1133394778
245/70R19.5	141/140K	-	H/16PLY	33.2	9.6	-	-	7.5	16.0	125	5675	125	5510	1133394796
245/70R19.5	136/134K	-	H/16PLY	33.2	9.6	-	-	7.5	16.0	120	4940	120	4675	1133394797
255/70R22.5	140/137N	-	H/16PLY	36.6	10.0	-	-	7.5	16.0	115	5510	115	5070	1133395727
255/70R22.5	140/137N	-	H/16PLY	36.6	10.0	-	-	7.5	16.0	120	5510	120	5070	1133395726
265/70R19.5	143/141K	-	H/16PLY	34.3	10.0	-	-	7.5	16.0	125	6010	125	5670	1133396796
275/70R22.5	148/145M	-	H/16PLY	37.8	10.6	-	-	8.25	16.0	131	6930	131	6380	1133397726
285/70R19.5	145M	-	H/16PLY	-	-	8.2	8.2	-	16.0	123	6390	-	-	1133398796

Recommended tires for 285/70R19.5

Best value

Double Coin RT500

Commercial All Position
285/70R19.5

145M

tires
easy test score

7.8 Great

Rims Not Included

Per Tire:

$270.78

Estimated Delivery

Shipping

Installation available

See details

Best deal

Continental Conti Hybrid HS3

Trailer
285/70R19.5

146/144M

tires
easy test score

10.0 Superb

Rims Not Included

Per Tire:

$487.36

Estimated Delivery

Shipping

Installation available

See details

Top rated

Continental Conti Hybrid HS3

Trailer
285/70R19.5

146/144M

tires
easy test score

10.0 Superb

Rims Not Included

Per Tire:

$487.36

Estimated Delivery

Shipping

Installation available

See details

Reviews

Jul 14, 2021 by Kelley L.

These tires are great .

"we have had real good results out of these tires ."

Jan 31, 2018 by someone w.

nice tires in a size that is hard to find.

"a very well made tire,I trust it on my vintage RV."

Jul 2, 2017 by Daniel L.

They are great tires so far.

"I have installed 4 tires on my trailer so far. They have upheld very hot temperatures. I have had to jump curbs with them. No damage so far. I will continue to purchase more tires in the future."

Sep 21, 2017 by Daniel L.

Great tires.

"I mounted them on my stepdeck trailer. I've jumped curbs with them and carried heavy loads. Excellent tires."

Dec 25, 2017 by Jd a.

Bang for the buck

"We all know Tht 17.5s are a struggle to keep from wearing funky these are paired next to a set of bridgestones and arnt wearing bad at all I will definatly buy them when I need more the Bridgestone at 500 a pop don’t do anything better then these don’t hesitate"

May 7, 2017 by Winnebago d.

I continue to use these tires

"I've never used any other tires on my motorhome these have always worked well, great smooth ride, I replace them every 4-5 yrs."

Jul 11, 2019 by Ricky B.

Good tires

"Very good tires all I run on my trailer they made the purchase easy will be buying from them again"

Sep 6, 2022 by Brandon

Cheap tires but ok

"We abuse tires on rollbacks wouldn’t recommend for a hard used truck. Maybe a RV or something that isn’t used for 500 plus miles a day"

Sep 15, 2022 by BillyJackds h.

Good tires

"Good cheap tires"
