Doublestar DS10 255/70R16 111T BSW

Truck/SUV - Highway
All Season

easy test score

8.5 Excellent

Availability

In Stock

Per Tire:

$72.87

Estimated Delivery

Shipping

Total

See full specs

About the Manufacturer:

Doublestar Tires, a brand of Doublestar Group, is a value oriented tire brand backed by a Qingdao based state controlled enterprise with origins dating to 1921. Official company materials highlight Doublestar’s focus on passenger, truck and bus, giant mining, and aircraft tires, supported by Industrial 4.0 smart manufacturing, a global research and development center, and production bases in Qingdao, Shiyan, and Cambodia. Doublestar positions itself as a dependable choice for drivers and commercial operators seeking safety focused technology, durable performance, and practical value across everyday, commercial, and heavy duty applications

Chat

Start chat

Call

(866) 335-8473

We can help! Our trained experts have years of tire fitment experience and are available to answer questions.

Specifications

Specs

Value

Description

Sidewall

BSW

Describes the sidewall appearance. Examples: BSW= Black Side Wall, WSW = White Side Wall, OWL = Outlined White Letters.

Load Index

111

The load index (LI) is a 2- or 3-digit number that correlates to the maximum amount of weight the tire can carry. For example, a tire with a load index of 87 indicates that the tire can carry a maximum load of 1,201 lbs. In this particularly example, 4 tires (each with a load index of 87) can carry a maximum of 4,804 lbs. Refer to your vehicle owner's manual for the recommended minimum load index.

Speed Rating

Speed rating (SR) indicates the maximum speed the tire can achieve. Higher speed ratings are typically associated with better handling capabilities. Refer to your vehicle owner's manual for the recommended minimum speed rating.

Load Range/Ply Rating

Not Available

Ply rating, more commonly referred to as load range, represents the strength and durability of the tire. Higher ratings may indicate your tires can handle heavier loads.

UTQG

600AB

To help consumers evaluate their tires, the U.S. National Highway Traffic Safety Administration (NHTSA) created the Uniform Tire Quality Grading System (UTQG). The UTQG rates tires are rated on their tread-wear, traction performance, and temperature resistance. The grade for each of these can be found on the sidewall of your tire (except for winter tires and certain light truck tires).

Max Single Load(lbs)

2403

The maximum load this tire will support. Remember to multiply this number by the number of tires installed on your vehicle to get the maximum carrying capacity. This number is directly related to the Load Index.

Max Single Air Pressure(PSI)

The maximum air pressure this tire will support. This does not represent the amount of air pressure your tires should have at all times. Consult with your owner's manual to determine the best air pressure you should use for your vehicle.

Tread Depth

11.9

The amount of tread on the tire. Once the tire is worn to 2/32nds, it is considered fully used and should be replaced at that time. Most tires will have tire indicators in the grooves of the tire to help you determine when the tires are worn down to 2/32nds.

Tread Design

Nondirectional

The pattern of the grooves, lugs, voids, and sipes on a tire's surface. This design affects the tire's traction, handling, and noise characteristics. Common types include symmetrical (uniform pattern across the tire), asymmetrical (different patterns on the inside and outside for varied road conditions), and directional (designed to rotate in one direction for improved wet traction and hydroplaning resistance).

Rim Width Range

Not Available

The approved wheel rim width range this tire will support.

Measured Rim Width

7.5

The recommended wheel width as recommended by the tire manufacturer to get the best wear us performance for this tire.

Section Width

10.2

The measurement from sidewall to sidewall.

Tread Width

Not Available

The measurement from one side of the tread to the other side of the tread.

Overall Diameter

30.0

The height of the tire when fully inflated.

Manufacturer Part Number

5PS02557016E000001

Manufacturer part number (sku)

Size Details

Size	Load Index/ Speed index	UTQG	Overall Diameter	Section Width	Rim Width Min	Rim Width Max	Rim Width Meas	Tread Depth (in)	Max Single Air Pressure (PSI)	Max Single Load (lbs)	Max Dual Air Pressure (PSI)	Max Dual Load (lbs)	MFG #
225/70R16	101H	600AB	28.4	8.9	-	-	6.5	10.9	44	1819	-	-	5PS02257016E000001
LT225/75R16	115/112Q	-	29.2	8.7	-	-	-	11.9	80	2679	80	2469	5PS02257516E000001
235/70R16	106T	600AB	28.9	9.4	-	-	7.0	11.9	44	2094	-	-	5PS02357016E000001
235/75R15	105T	600AB	28.8	9.2	-	-	6.5	10.9	44	2039	-	-	5PS02357515E000001
245/65R17	107H	600AB	29.5	9.7	-	-	7.0	10.9	44	2149	-	-	5PS02456517E000001
245/70R16	107T	600AB	29.5	9.7	-	-	7.0	10.9	44	2149	-	-	5PS02457016E000001
245/70R17	110T	600AB	30.5	9.7	-	-	7.0	12.3	44	2337	-	-	5PS02457017E000001
LT245/75R16	120/116Q	-	30.4	9.7	-	-	-	12.9	80	3042	80	2778	5PST2457516E000001
LT245/75R17	121/118Q	-	31.4	9.7	-	-	-	12.4	80	3197	80	2910	5PST2457517E000001
255/70R16	111T	600AB	30.0	10.2	-	-	7.5	11.9	44	2403	-	-	5PS02557016E000001
265/60R18	109T	600AB	30.5	10.7	-	-	8.0	10.9	44	2271	-	-	5PS02656018E000001
265/65R17	112H	600AB	30.5	10.7	-	-	8.0	11.9	44	2469	-	-	5PS02656517E000001
265/70R16	112T	600AB	30.6	10.7	-	-	8.0	11.9	44	2469	-	-	5PS02657016E000001
265/70R17	115T	600AB	31.6	10.7	-	-	8.0	12.9	44	2679	-	-	5PS02657017E000001
LT265/75R16	123/120Q	-	31.6	10.5	-	-	-	12.9	80	3417	80	3086	5PST2657516E000001
